Milling

No matter which challenge, EMCO has the fitting solution. Customized to the individual requirements of your company.

Vertical Milling Centers

Umill 1500 - Umill 1800 - Linearmill - Dynamill - Megamill - Powermill

DYNAMILL G5 — Symbolic picture

DYNAMILL G5

15° undercut on universal milling head with high-speed spindle
Direct drive technology on all milling heads with high-speed spindle
Automatic tool changer up to 128 tools

DYNAMILL — Symbolic picture

DYNAMILL

X axis from 4550 mm and more
Y axis 3000 - 4000 mm
Z axis 1500 - 2000 - 2500 mm
Max. drive power 60 kW (S1)
Max. drive torque 600 Nm (S1)
Axes feed rate 40 m/min

MEGAMILL — Symbolic picture

MEGAMILL

X axis from 7500 mm and more
Y axis 4000 - 5000 - 6000 - 7000 mm
Z axis 1500 - 2000 mm
Max. drive power 40 kW (S1)
Max. drive torque 1200 Nm (S1)
Axes feed rate 30 m/min

POWERMILL — Symbolic picture

POWERMILL

X axis from 6000 mm and more
Y axis 4000 - 5000 - 6000 - 7000 mm
Z axis 1500 - 2000 mm
Max. drive power 40 kW (S1)
Max. drive torque 1200 Nm (S1)
Axes feed rate 30 m/min

Horizontal Milling Machines

Ecomill - Ecomill Plus - Mecmill - Mecmill Plus

ECOMILL — Symbolic picture

ECOMILL

X axis from 6000 mm and more
Y axis 1300 mm
Z axis 2500 mm
Max. power spindle motor 60 kW (S1)
Max. torque spindle motor 600 Nm (S1)
Axes feed rate 30 m/min

ECOMILL PLUS — Symbolic picture

ECOMILL PLUS

X axis from 6000 mm and more
Y axis 1600 mm
Z axis 3000 mm
Max. power spindle motor 60 kW (S1)
Max. torque spindle motor 600 Nm (S1)
Axes feed rate 30 m/min

MECMILL — Symbolic picture

MECMILL

X axis from 6000 mm and more
Y axis 1600 mm
Z axis 3500 mm
Max. power spindle motor 40 kW (S1)
Max. torque spindle motor 1200 Nm (S1)
Axes feed rate 30 m/min

MECMILL PLUS — Symbolic picture

MECMILL PLUS

X axis from 6000 mm and more
Y axis 1600 - 1800 mm
Z axis 4000 - 5000 mm
Max. power spindle motor 40 kW (S1)
Max. torque spindle motor 1200 Nm (S1)
Axes feed rate 25 m/min

Umill

Universal Machining Center for 5-axes machining

UMILL 1800 — Symbolic picture

UMILL 1800

X axis travel 1800 mm
Y axis travel 2150 mm
Z axis travel 1250 mm
Axes feed rate 60 m/min

Umill 1500 — Symbolic picture

Umill 1500

X-Axis 1500 mm
Y-Axis 1500 mm
Z-Axis 1100 mm
Axes Feed rate 60 m/min

Umill 750

Umill 750

X-Axis 750 + 50 mm
Y-Axis 610 mm
Z-Axis 500 mm
Rapid motion speed 50 m/min

Umill 630

Umill 630

X-Axis 550 + 50 mm
Y-Axis 460 mm
Z-Axis 450 mm
Rapid motion speed 50 m/min

MMV

Universal Travelling Column Machining Center for 3- to 5-axes machining

With linear motors in X and Y axis; Travel in X: up to 3200 mm

MMV 3200 — Symbolic picture

MMV 3200

Travel in X/Y/Z 3200/1000/950 mm
Clamping area 3500 x 1050 mm
Max. table load 5000 kg
Max. speed spindle 15000 / 18000 rpm

MMV 2000 — Symbolic picture

MMV 2000

Travel in X/Y/Z 2000/800/750 mm
Clamping area 2400 x 950 mm
Max. table load 2200 kg
Table-floor distance 1000 mm
Max. speed spindle 15000 rpm

Maxxmill

Universal Machining Center for 5-side operation

For the 5 side machining of workpieces up to 530 x 530 x 417 mm edge length; Max. travel in X: up to 650 mm

Maxxmill 750 — Symbolic picture

Maxxmill 750

Max. Travel in X 750+50mm
Clamping Area 750 x 600 mm
Max. Workpiece weight 300 kg
Max. Speed Range 50 - 12.000 / Motorspindel 15.000 rpm
Number of tool stations (optional) 30 (40/60)

Maxxmill 630 — Symbolic picture

Maxxmill 630

Max. Travel in X 500+50 mm
Clamping Area 630 x 500 mm
Max. Workpiece Weight 200 kg
Max. Speed Range 50 - 12.000 / Motorspindel 15.000 rpm
Number of Tool Stations (option) 30 (60)

Maxxmill 400 — Symbolic picture

Maxxmill 400

Max. travel in X 350+100mm
Clamping area 400 mm Diameter
Max. table load 80 kg
Max. spindle speed 12,000 / 24,000 rpm
Number of tool stations 30

Emcomill E Series

Vertical 3-Axes Machining Center

Vertical milling centers with C-frame design. Travel in X: from 350 to 1200 mm

Emcomill E350 — Symbolic picture

Emcomill E350

Max. travel in X 350 mm
Clamping area 500 x 300 mm
Max. table load 100 kg
Max. spindle speed 10000 rpm
Number of tool positions 20

Emcomill 750 — Symbolic picture

Emcomill 750

Max. travel in X 750 mm
Clamping area 900 x 630 mm
Max. table load 800 kg
Max. speed 15000 rpm
Number of tool stations 30 (40)

Emcomill 1200 — Symbolic picture

Emcomill 1200

Max. travel in X 1200 mm
Clamping area 1300 x 630 mm
Max. table load 1500 kg
Max. speed 15000 rpm
Number of tool stations 30 (40)

EMCOMAT FB-Series

Universal milling machines with and without cycle control

Emcomat FB-3 — Symbolic picture

Emcomat FB-3

Clamping area 600 x 200 mm
Max. table load 50 kg
Max. speed 2200 rpm
Drive power milling spindle 1.4 kW

Emcomat FB-450 MC — Symbolic picture

Emcomat FB-450 MC

Clamping area 800 x 400 mm
Max. table load 300 kg
Max. speed 5000 rpm
Power milling spindle 10 kW

Emcomat FB-600 MC — Symbolic picture

Emcomat FB-600 MC

Clamping area 800 x 400 mm
Max. table load 300 kg
Max. speed 5000 rpm
Power milling spindle 13 kW
