| Travel in X/Y/Z | 1100 / 600 / 600 |
| Number of axes (basic machine) | 3 |
| Rapid motion speeds in X/Y/Z | 36 |
| Max. table load | 800 |
| Max. speed | 50 - 12000 rpm |
| Max. drive power | 13,6 kW |
| Max. torque | 95 Nm |
| Number of tool stations | 30 |
| Tool changing time (tool to tool) | 2,5 sec |
| Max. tool diameter | 76 mm |
| Max. tool length | 300 mm |
| Dimensions (LxWxH) | 2800 x 2245 mm |
| Machine weight | 6500 kg |
